Rotax 876-970 Piston Ring Spanner 72 MM
- a for installation of cylinder on the piston 67,5 mm.
- b for installation of cylinder on the piston 72 mm.
- c to hold the fan.
- d for aligning of cylinders at the intake flange.
- e for crankshaft bearing P.T.O. side.
- f for positioning of crankshaft bearing P.T.O. side.
- g for centering of the stator plate.
- h for piston pin 18 mm.
- i for installation of piston pin circlip 18 mm.
- j for the engine.
- k without ignition and externals.
Explanations of symbols and statements in charts:
- N = Newly introduced
- s.v. = Still valid. Part was replaced by compatible component and can not be supplied any longer by the producer. Existing stock may be used.
- AR = As required. This generally refers to shims, hose, wires, and cable. Measure the amount you need before ordering. Many times there will be multiple listings of different lengths with the same . Use individual part descriptions to determine the proper length needed.
- n.a or NLA = No longer available, no replacement from Rotax. Part is no longer available due to incompatibility to current production or unavailability of part.
- CALL = Please call for price, 800-247-9653
Original price
$73.12
-
Original price
$73.12
Original price
$73.12
$73.12
-
$73.12
Current price
$73.12
